WCB Wafer Butterfly Valve with Rotary Electric Valve Actuator Features
1. Voltage: 24VAC, 110VAC, 220VAC, 380VAC, 24VDC
2. Type: On-off, Regulating, Passive Contact
3. Sealing: PTFE
WCB Wafer Butterfly Valve with Rotary Electric Valve Actuator Specifications
1). Nominal Diameter: DN50-300
2). Pressure Range: 0-1.0MPa
3). Medium Temp.: -20°C~+120°C
4). Valve Body Material: Gray cast iron, ductile cast iron, cast steel, stainless steel
5). Sealing Material: NBR, EPDM, FPM
6). Valve Disc Material: Ductile cast iron, cast steel, stainless steel, nickel alloy
8). Feature: Double bubble and zero leakage
9). Applicable Medium: Drinking water,sewage,high purity water,sea water,air, etc.
10). Controlling Voltage: AC24V, 110V, 220V, 380V, DC24V
11). Type: On-off, Regulating, Passive Contact
12). Manufacture Standard: GB, ISO, ANSI, DIN
| Brand: | KST/OEM |
| Applicable Media: | Water, Oil, Gas, Nitric Acid, Acetic Acid |
| Normal Pressure: | 0-1.0MPa |
| Strength Testing Pressure: | PT 2.4,3.8,6.0,9.6Mpa |
| Seat Testing Pressure(Low Pressure): | 0.6Mpa |
| Applicable Temp: | -20°C-180°C |
| Certification: | CE/API/DNV/FDA/ISO9001-2008 |
| Sample Testing: | One Sample for free( Under $10),Freight Collect |
| Packing: | Plastic Bag, Carton & Plywood Case/According to customers' requirement. |
| Payment: | T/T, L/C, D/P, Western Union, Paypal |
| Port: | NINGBO/SHANGHAI, Customers' Request |
| Delivery Time: | Within 35days after receiving T/T deposit Payment |
| Term of Delivery: | FOB/CNF/CIF, Customers' Request |
